درایور ماسفت IR2111 پکیج PDIP-8

آی سی IR2111 یک درایور HALF-BRIDGE می باشد که برای راه اندازی ماسفت و IGBT می شود.

Product Category:     Gate Drivers
RoHS:     RoHS Compliant Details
Mounting Style:     Through Hole
Package/Case:     PDIP-8
Product:     Half-Bridge Drivers
Number of Drivers:     2 Driver
Output Current:     200 mA
Configuration:     Inverting, Non-Inverting
Rise Time:     130 ns
Fall Time:     65 ns
Supply Voltage – Max:     20 V
Supply Voltage – Min:     10 V
Operating Supply Current:     180 uA
Maximum Operating Temperature:     + 125 C
Type:     High and Low Side Driver
Features:     Synchronous
Height:     5.33 mm (Max)
Length:     10.92 mm (Max)
Logic Type:     CMOS
Maximum Turn-Off Delay Time:     150 ns
Maximum Turn-On Delay Time:     750 ns
Minimum Operating Temperature:     – 40 C
Number of Outputs:     2
Operating Supply Voltage:     10 V to 20 V
Pd – Power Dissipation:     1000 mW
Propagation Delay – Max:     950 ns
Factory Pack Quantity:     50
Width:     7.11 mm (Max)
Unit Weight:     1 g
