ماسفت قدرت 17NF25 نوع N-Channel مارک ST پکیج TO-220FP
ماسفت قدرت 250 ولت 17 آمپر 17NF25 مارک ST نوع N-Channel پکیج TO-220FP
Type Designator: STF17NF25
Marking Code: 17NF25
Type of Transistor: MOSFET
Type of Control Channel: N -Channel
Maximum Power Dissipation (Pd): 25 W
Maximum Drain-Source Voltage |Vds|: 250 V
Maximum Gate-Source Voltage |Vgs|: 20 V
Maximum Gate-Threshold Voltage |Vgs(th)|: 4 V
Maximum Drain Current |Id|: 17 A
Maximum Junction Temperature (Tj): 150 °C
Total Gate Charge (Qg): 29.5 nC
Rise Time (tr): 17.2 nS
Drain-Source Capacitance (Cd): 178 pF
Maximum Drain-Source On-State Resistance (Rds): 0.165 Ohm
Package: TO220FP
| Manufacturer | |
|---|---|
| Package/Case | |
| Type | |
| Continuous Drain Current (Id) | |
| Drain Source Voltage (Vdss) | |
| Power Dissipation (Pd) | |
| Drain Source On Resistance (RDS(on)@Vgs,Id) |
